Application Examples
Hypoid gear / Automobile / ID, OD
Overview
| Type of industry | Automobile |
|---|---|
| Type of part | Automobile part |
| Name of part | Hypoid gear |
| Material | SCM415 |
| Dimension | ø72 mm(2.8 in)×12 mm(0.4 in) |
| Grinding surface | ID, OD |
| Roundness | ID: 0.95μm(0.00004 in) OD: 0.55μm(0.00003 in) |
| Surface roughness | ID: Ra 0.6μm(0.00003 in) OD: Ra 0.8μm(0.00004 in) |
| Coaxiality | 2μm(0.00008 in) |
| Cycle time | 75 sec.（PGV-3） |
